Ozone (O3) Gas Sensor

Price: ₹14000(Excluding GST)

Condition: New

Availability: In stock

   Tenacious's Ozone gas transmitter is a electrochemical based ozone gas detection sensor. It utilizes electrochemical principle to detect O3 in air, which makes the sensor with high selectivity and stability. A built-in temperature sensor can do temperature compensation, and it has analog 4-20 mA or 0-10 v output and Digital Modbus RS485-RTU output.The TO3 Transmitter measuring range has 0-10ppm and 0-100ppm two types.

Potential Applications :

• Ozone disinfection cabinet
• Air quality detection
• Water disinfection
• Food processing and Storage
• Medical hygiene

Technical Specification :

• Sensing Technology: Electrochemical
• Sensor life expectancy: ≥ 2 years under ideal condition
• Measuring Range: 0 to 10 ppm, 0 to 100 ppm
• Resolution: 0.01ppm for 0-10ppm,0.1ppm for 0-100ppm
• Accuracy: ±6 FS (@25Degc and 50% RH)
• Warmig Uptime: 15Min
• Response Time: 30 Sec
• Preheating time: 30 sec.
• Power supply: 24Vdc/ac   (*Modbus Model Only Working on dc supply)
• Power Consumption: 40 mA max.@24Vdc for 4 to 20 mA Output Model, 30 mA max.@24Vdc for 0 to 10V/Modbus
• Analog 4-20mA output signal load resistance: 500ohm Max.
• Analog 0-10V output signal load resistance: 10k Min.
